Hardware
Standard&Protocol
IEEE802.3, IEEE802.3u
CPU
1GHz
RAM
32MB
Interfaces
1*10/100Mbps WAN port
3*10/100Mbps LAN ports
Antenna
4*6dBi external antennas
Button
1* Wi-Fi / Reset button
Power
Input：100-240V—50/60Hz 0.4A
Output：DC 9V1A
LED Indicator
Sys*1
Dimension
200*127*33.6mm
Wireless
Wireless Standard
IEEE 802.11ac/a/n @5GHz
IEEE 802.11b/g/n @2.4GHz
Data Rate
5.7GHz: Up to 867Mbps
2.4GHz: Up to 300Mbps
Frequency
2.4G: 2412-2472MHz(CH1-CH13)
5.7G: 5725-5825MHz(CH149-CH165)
Transmission Power
CE:
<20 dBm (2.4 GHz)
<23 dBm (5 GHz)
FCC:
<30 dBm (2.4 GHz)
<30 dBm (5 GHz)
Wireless Security
WPA2-PSK
Wireless Security : Enable /Disable
Software
Internet Connection Type
PPPoE, Dynamic IP, Static IP
PPPoE(Russia), PPTP(Russia), L2TP(Russia)
Unify,Maxis,Maxis-special,Celcom,Digi
Network Protocol
IPv4&IPv6
Operating Mode
Router Mode
AP Mode
Universal Repeater Mode（Client+AP,WISP）
Parental Control
Client Filter
URL Filter
Time Limit
DHCP
DHCP Server
DHCP Client List
DHCP Static IP Address Reservation and Allocation
Virtual Server
Port Forwarding, DMZ Host, UPnP
Firewall
ICMP Flood Attack Defense
TCP Flood Attack Defense
UDP Flood Attack Defense
Block Ping From WAN
DDNS
DynDNS, no-ip, oray, 88ip
VPN
IPsec pass through
PPTP pass through
L2TP pass through
Special Features
Guest Network
IPTV
Signal Adjustment
Basic Functions
PPPoE Username/password Clone
Smart WiFi Schedule
Smart Power Saving
Smart LED on/off
Tenda App
Dual-band in One
IPv6 Features Supported
Broadband management
MAC address clone
Backup & Restore configurations
Firmware upgrade from local
Others
Temperature
Operating Temperature : 0℃~40℃
Storage Temperature : -40C ~70℃
Humidity
Operating Humidity : 10 %~90% RH non-condensing
Storage Humidity : 5 %~ 90%RH non-condensing
Certification
CE, FCC,RoHS
Package Contents
Wi-Fi Router *1
RJ45 Ethernet Cable*1
Power Adapter*1
Quick Installation Guide*1
